Image Device

Cmos Sensor Sony IMX415

Pixel Size

1.45μm x 1.45μm

Resolution

8.3MP 3840(H) x 2160(V)

Output Format

MJPEG/YUY2

Shutter Type

Rolling Shutter

Focus

Auto-Focus

Focusing Range

20mm to Infinity

Protocol& Connection

Plug-&-Play (UVC compliant)

Frame Rate

3840x2160  @30fps MJPEG  1fps YUY2

2592x1944  @30fps MJPEG  1fps YUY2

2048x1536  @30fps MJPEG  3fps YUY2

1600x1200  @30fps MJPEG  5fps YUY2

1920x1080  @30fps MJPEG  5fps YUY2

1280x960  @30fps MJPEG  5fps YUY2

1280x720  @30fps MJPEG  10fps YUY2

800 x 600  @30fps MJPEG  30fps YUY2

640x480  @30fps MJPEG  30fps YUY2

320x240  @30fps MJPEG 30fps YUY2

OTG

Support

Minimum Illumination

0.01 LUX

WDR

75dB

Lens

120 Degree No-Distortion Autofocus Lens,other can be optional

IR-Cut Filter

(IR Filter)

Default at 650nm, custom options 850,940nm.

Night Vision

Supported with the use of white flash LED’s ONLY

Microphone

Available upon request

Controllable Features

Brightness,Contrast,Saturation,Hue,Sharpness,Gamma,White balance,Backlight Contrast,Exposure

IR Illumination

Default not available, 12 or 24pcs 850nm/940nm IR

LED board can be customized upon request

Power Socket

4Pin Socket, USB BUS Power

Cable Length

Default 1.2Meter (others upon request)

Supported OS

Win XP/Vista/Win7/Win8/Win10

Linux with UVC (linux-2.6.26 or later)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or higher with UVC

Power Consumption

DC5V (±5%), 380mA

Operating Temp.

-20°C~+70°C

Storage Temp.

-30°C~+80°C

Humidity

Less than 80%

Dimension

38x38mm

Weight

Approx. 12 Grams or 0.4 Ounce

Windows OS

AMCAP etc.

Linux OS

V4L2 etc.

Mac OS

Facetime etc.

Android OS

CameraFi etc.
