Image Device

Cmos Image Sensor Sony IMX179

Pixel Size

1.4μm x 1.4μm

Resolution

8 MP 3264(H) x 2448(V)

Output Format

MJPEG / YUY2

Shutter Type

Electronic Rolling Shutter

Focus

AutoFocus

Protocol& Connection

Plug-&-Play (UVC compliant)

Frame Rate

3264×2448   MJPEG @15fps   YUY2 @2fps

2592×1944    MJPEG @20fps   YUY2 @2fps

2048×1536    MJPEG @20fps    YUY2 @3fps

1920×1080    MJPEG @30fps    YUY2 @5fps

1600×1200    MJPEG @20fps    YUY2 @5fps

1280×720     MJPEG @30fps    YUY2 @10fps

800×600      MJPEG @20fps    YUY2 @20fps

640×480      MJPEG @30fps    YUY2 @30fps

OTG

Support

Minimum Illumination

0.05 LUX

Lens

AutoFocus Lens 70 Degree

IR-Cut Filter

(IR Filter)

Default at 650nm, custom options 850,940nm.

Night Vision

Supported with the use of white flash LED’s ONLY

Controllable Features

Brightness,Contrast,Saturation,Hue,Sharpness,Gamma,White balance,Backlight Contrast,Exposure

IR Illumination

Supported when supplied with IR LED

Power Socket

4Pin Socket, USB BUS Power

Cable Length

Default 1.0Meter (others upon request)

Supported OS

Win XP/Vista/Win7/Win8/Win10

Linux with UVC (linux-2.6.26 or later)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or higher with UVC

Power Consumption

DC5V (±5%), 150~200mA

Operating Temp.

-20°C~+70°C

Storage Temp.

-30°C~+80°C

Humidity

Less than 80%

Dimension

38x38mm(Mount compatible with 32x32mm)

Weight

Approx. 12 Grams or 0.4 Ounce

Windows OS

AMCAP etc.

Linux OS

V4L2 etc.

Mac OS

Facetime etc.

Android OS

CameraFi etc.
