Image Device

Cmos Sony IMX598 Sensor

Pixel Size

1/2 inch

Resolution

48 MP 8000(H) x 6000(V)

Output Format

MJPEG

Shutter Type

Electronic Rolling Shutter

Focus

Manually

Focusing Range

20mm to Infinity

Protocol& Connection

Plug-&-Play (UVC compliant)

Frame Rate

8000x6000   MJPEG @5fps

4608x3456    MJPEG @15fps

4000x3000    MJPEG @15fps

3840X2160    MJPEG @30fps

2592X1944    MJPEG @30fps

OTG

Support

Minimum Illumination

0.1 LUX

Lens

Default Non-distortion 100 degree FOV lens,other can be optional

IR-Cut Filter

(IR Filter)

Default at 650nm, custom options 850,940nm.

Night Vision

N/A

Auto Features

Brightness,Contrast,Saturation,Hue,Sharpness,Gamma,White balance,Backlight Contrast,Exposure

IR Illumination

N/A

Power Socket

4Pin Socket, USB BUS Power

Cable Length

Default 1.5Meter (others upon request)

Supported OS

Win XP/Vista/Win7/Win8/Win10

Linux with UVC (linux-2.6.26 or later)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or higher with UVC

Power Consumption

DC5V (±5%), 600mA

Operating Temp.

-10°C~+60°C

Storage Temp.

-20°C~+70°C

Humidity

Less than 80%

Dimension

38x38mm

Weight

Approx. 12 Grams or 0.4 Ounce

Windows OS

AMCAP etc.

Linux OS

V4L2 etc.

Mac OS

Facetime etc.

Android OS

CameraFi etc.
