Image Device

Sony Cmos Sensor 1/2.8” IMX335

Pixel Size

2μm x 2μm

Resolution

5MP 5120(H) x 1440(V)

Output Format

MJPEG/YUY2

Shutter Type

Rolling Shutter

Focus

Manually

Focusing Range

250px to Infinity

Protocol& Connection

Plug-&-Play (UVC compliant)

Frame Rate

(2x2560)x1440   MJPEG @60fps    YUY2 @10fps

(2x2592)x1944    MJPEG @10fps    YUY2 @10fps

(2x1280)x720    MJPEG @60fps    YUY2 @60fps

Interface

USB-Type-C 3.0

OTG

Support

Lens Parameters

DFOV:82° HFOV:71°VFOV:58°

TTL：22.7mm

F(NO.):2.7

BFL:3.24mm

Optical Distortion Rate:<0.5%

IR-Cut Filter

(IR Filter)

Default at 650nm, custom options 850,940nm.

Night Vision

N/A

S/N Radio

42dB

Dynamic Range

72dB

Controllable Features

Brightness,Contrast,Saturation,Hue,Sharpness,Gamma,White balance,Backlight Contrast,Exposure

IR Illumination

Default not available, 850nm/940nm IR

LED board can be customized upon request

Power Socket

USB BUS Power

Cable Length

Default 1.0Meter (others upon request)

Supported OS

Win XP/Vista/Win7/Win8/Win10

Linux with UVC (linux-2.6.26 or later)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or higher with UVC

Power Consumption

DC5V (±5%) 330mA

Operating Temp.

-10°C~+65°C

Storage Temp.

-20°C~+70°C

Humidity

Less than 80%

Dimension

Board 94mm(L)x28mm(W)

Weight

Approx. 100g

Windows OS

AMCAP etc.

Linux OS

V4L2 etc.

Mac OS

Facetime etc.

Android OS

CameraFi etc.
