Image Device

Cmos Sensor 1/4” OV9281

Pixel Size

3μm x 3μm

Resolution

1 MP 1280(H) x 720(V)


Monochrome Vision

Output Format

MJPEG

Shutter Type

Global Shutter

Focus

Manually

Focusing Range

20mm to Infinity

Protocol& Connection

Plug-&-Play (UVC compliant)

Frame Rate

160X120      MJPEG @120fps

176X144      MJPEG @120fps

320X240      MJPEG @120fps

352X288      MJPEG @120fps

424X240      MJPEG @120fps

640X360      MJPEG @120fps

640X400      MJPEG @120fps

960X540      MJPEG @120fps

1280X720     MJPEG @120fps

OTG

Support

Minimum Illumination

0.05 LUX

Lens

Default 4MM CS Mount Lens,other can be optional

IR-Cut Filter

(IR Filter)

Default at 650nm, custom options 850,940nm.

Night Vision

Supported with the use of white flash LED’s ONLY

Controllable Features

Brightness,Contrast,Saturation,Hue,Sharpness,Gamma,White balance,Backlight Contrast,Exposure

IR Illumination

N/A

Power Socket

4Pin Socket, USB BUS Power

Cable Length

Default 1.0Meter (others upon request)

Supported OS

Win XP/Vista/Win7/Win8/Win10

Linux with UVC (linux-2.6.26 or later)

MAC-OS X 10.4.8 or later

Wince with UVC

Android 4.0 or higher with UVC

Power Consumption

DC5V (±5%), 100~160mA

Operating Temp.

-10°C~+60°C

Storage Temp.

-20°C~+70°C

Humidity

Less than 80%

Dimension

50x50x40mm

Weight

Approx. 0.25kg

Windows OS

AMCAP etc.

Linux OS

V4L2 etc.

Mac OS

Facetime etc.

Android OS

CameraFi etc.
